Features:
2/2 way direct lifting diaphragm type
0-10bar
Flow channel 15-50mm
Detachable repair
Sealing material: NBR rubber - EPDM rubber - fluoro rubber -specific material
Suitable for water, air, water vapor, light oil, natural gas, etc.
Provide lP65 three-pole connector in accordance with UNl ISO 4400 (DIN 43650A/ lead connection /explosion-proof coil
Product features
| General characteristics | |||
| Body material | Stainless steel | ||
| Sealing material | NBR | EPDM | VITON |
| Temperature | 80℃ | 140℃ | 150℃ |
| Insulation grade | H | ||
| Voltage | 220-230VAC 50-60Hz | 100-120VAC 60Hz | 12-24DC |
| Power | 15-28VA | 15-28VA | 15-20W |
| Ambient temperature | -10℃-80℃ | ||
| Installation | Installed according to the flow direction of the valve body.to improve the life and reliability, install it horizontal upward is best | ||
| Connection | The standard is G, and the thread requirements such as NPT can be selected. | ||
| Voltage fluctuation | ±10% | ||
| Can be equipped with coil | B41/B51/A42F | ||
| Specification sheet (internal thread interface) | |||||||||||
| Flow aperturemm mm | KV value m3/h | Pressure difference(BAR) | Model(voltage is 220v) | Weight KG | |||||||
| MiniMum pressure | Maximum working pressure | ||||||||||
| Air，gas | Water, liquid | Light oi | |||||||||
| AC | DC | AC | DC | AC | DC | ||||||
| 15 | 2.1 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | ZS-15F-42X | 1.8 | |
| 20 | 5.7 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | ZS-20F-52X | 2.0 | |
| 25 | 9.6 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | ZS-25F-62X | 2.9 | |
| 32 | 22 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | ZS-32F-72X | 5.1 | |
| 40 | 27 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | ZS-40F-82X | 6.1 | |
| 50 | 35 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | ZS-50F-92X | 8.2 | |
| 65 | 46 | 0 | 10 | 7 | 6 | 7 | 3 | 2 | ZS-65F-A2X | 15.2 | |
| 80 | 56 | 0 | 10 | 7 | 6 | 7 | 3 | 2 | ZS-80F-B2X | 18 | |
| 100 | 68 | 0 | 10 | 7 | 6 | 7 | 3 | 2 | ZS-100F-C2X | 23.5 | |
