Features:
2/2way direct lifting diaphragm type
0-8bar
Flow channel 15-50mm
Detachable repair
Sealing material: NBR rubber - EPDM rubber - fluoro rubber- specific material
Suitable for water, air, water vapor, light oil, natural gas, etc.
lead connection
Product features
| General characteristics | |||
| Body material | Stainless steel | ||
| Sealing material | NBR | EPDM | VITON |
| Temperature | 80℃ | 140℃ | 150℃ |
| Insulation grade | H | ||
| Voltage | 220-230VAC 50-60Hz | 100-120VAC 60Hz | 12-24DC |
| Power | 22VA | 22VA | 18W |
| Ambient temperature | -10℃-80℃ | ||
| Installation | Installed according to the flow direction of the valve body.to improve the life and reliability, install it horizontal upward is best | ||
| Connection | The standard is G, and the thread requirements such as NPT can be selected. | ||
| Voltage fluctuation | ±10% | ||
| Can be equipped with coil | A32/A42 | ||
| Specification sheet | ||||||||||||
| Flow aperturemm mm | KV value m3/h | Pressure difference(BAR) | Model(voltage is 220v)X=N or E or V | Weight KG | ||||||||
| MiniMum pressure | Maximum working pressure | |||||||||||
| Air, gas | Water, hot water | Light oi | ||||||||||
| AC | DC | AC | DC | AC | DC | |||||||
| 15 | 2.1 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | 2W-15F-42X | 1.8 | ||
| 20 | 5.7 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | 2W-20F-52X | 2.0 | ||
| 25 | 9.6 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | 2W-25F-82X | 2.9 | ||
| 32 | 22 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | 2W-32F-72X | 5.1 | ||
| 40 | 27 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | 2W-40F-82X | 6.1 | ||
| 50 | 35 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | 2W-50F-92X | 8.2 | ||
