Features:
3/2 way direct acting type
0-25bar
Flow channel 1.0-4.0mm
Detachable repair
Sealing material: NBR rubber - EPDM rubber - fuoro rubber - specific material
Suitable for water, air, water vapor, light oil, natural gas, etc.
Provide lP65 three-pole connector in accordance with UNl ISO 4400 (DIN43650A)/lead connection
Product features
| General characteristics | |||
| Body material | Brass、Stainless steel | ||
| Sealing material | NBR | EPDM | VITON |
| Temperature | 80℃ | 140℃ | 150℃ |
| Insulation grade | H | ||
| Voltage | 220-230VAC 50-60Hz | 100-120VAC 60Hz | 12-24DC |
| Power | 22VA | 22VA | 15W/17W |
| Ambient temperature | -10℃-80℃ | ||
| Installation | Installed according to the flow direction of the valve body.to improve the life and reliability, install it horizontal upward is best | ||
| Connection | The standard is G, and the thread requirements such as NPT can be selected. | ||
| Voltage fluctuation | ±10% | ||
| Can be equipped with coil | B11/B21/B31/B32/E11 | ||
| Specification sheet | |||||||||||
| Connection way | Flow aperturemm mm | KV value m3/h | Pressure difference(BAR) | Model (voltage is 220v)X=N or E or V or F | |||||||
| MiniMum pressure | Maximum working pressure | ||||||||||
| Air, gas, Water, liquid | Light oil ≤20CST | Body material | |||||||||
| AC | DC | AC | DC | brass | stainless steel | ||||||
| 1/8" | 1.5 | 0.07 | 0 | 13 | 11 | 13 | 11 | STGT1-A3-11X | STGT1-A3-12X | ||
| 2.0 | 0.14 | 0 | 11 | 9 | 11 | 9 | STGT1-02-11X | STGT1-02-12X | |||
| 2.5 | 0.21 | 0 | 9 | 7 | 9 | 7 | STGT1-A4-11X | STGT1-A4-12X | |||
| 3.0 | 0.25 | 0 | 6 | 4 | 6 | 4 | STGT1-03-11X | STGT1-03-12X | |||
| 4.0 | 0.35 | 0 | 3.5 | 2 | 3.5 | 2 | STGT1-04-11X | STGT1-04-12X | |||
| 1/4" | 1.5 | 0.07 | 0 | 13 | 11 | 13 | 11 | STGT1-A3-21X | STGT1-A3-22X | ||
| 2.0 | 0.14 | 0 | 11 | 9 | 11 | 9 | STGT1-02-21X | STGT1-02-22X | |||
| 2.5 | 0.21 | 0 | 9 | 7 | 9 | 7 | STGT1-A4-21X | STGT1-A4-22X | |||
| 3.0 | 0.25 | 0 | 6 | 4 | 6 | 4 | STGT1-03-21X | STGT1-03-22X | |||
| 4.0 | 0.35 | 0 | 3.5 | 2 | 3.5 | 2 | STGT1-04-21X | STGT1-04-22X | |||
