2/2-Way Direct Lift Diaphragm
Working Pressure: 0–10 bar
Port Size: 15–50 mm
Detachable & Serviceable Design
Sealing Materials: NBR Rubber, EPDM Rubber, Viton Fluoroelastomer, Special Custom Materials
Media Compatibility: Water, Air, Steam, Light Oil, Natural Gas, etc.
Supplies IP65 3-pin connectors complying with UNI ISO 4400 (DIN 43650 Type A, cable lead connection, explosion-proof coil compatible)
Product features
一般特征 | |||
阀体材质 | 不锈钢 | ||
密封材料 | NBR | EPDM | VITON |
温度 | 80 ℃ | 140 ℃ | 150 ℃ |
压力范围 | 0-1.0MPA | ||
电压 | AC220-230V 50-60HZ | AC100-120 60HZ | DC12-24 |
力量 | 22 VA | 22 VA | 18 V |
环境温度 | -10 ℃ -80 ℃ | ||
安装 | 按阀体流向安装，为提高寿命和可靠性，最好水平向上安装 | ||
联系 | 标准为G，可选择NPT等螺纹要求。 | ||
电压波动 | ±10％ | ||
可配线圈 | A32/A42 | ||
绝缘等级 | H | ||
| 规格表（内螺纹接口） | ||||||||||||||
| 连接 方式 | 流通 孔径 mm | KV值 m3/h | 压差(BAR) | 尺寸 长 x 宽 x 高 AxBxC | 型号(电压为220v)X=N或E或V | 重量 公斤 | ||||||||
| 最小压力 | 最大工作压力 | |||||||||||||
| 空气、气体 | 水，液体 | 轻油 | ||||||||||||
| 交流 | 直流 | 交流 | 直流 | 交流 | 直流 | |||||||||
| 3/8” | 15 | 2.4 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | 70x57x100 | 2WS1-15-32X | 0.85 | ||
| 1/2” | 15 | 2.4 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | 70x57x100 | 2WS1-15-42X | 0.8 | ||
| 3/4” | 20 | 6.3 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | 72x57x107 | 2WS1-20-52X | 1.1 | ||
| 1” | 25 | 8.3 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | 98x76x115 | 2WS1-25-62X | 1.45 | ||
| 11/4” | 32 | 19.4 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | 112x86.5x150 | 2WS1-32-72X | 2.3 | ||
| 11/2” | 40 | 22.4 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | 123x94x160 | 2WS1-40-82X | 2.9 | ||
| 2” | 50 | 34.8 | 0 | 10 | 7 | 10 | 7 | 7 | 4 | 165x123x176 | 2WS1-40-92X | 4.8 | ||
一般特征 | |||
|
