Features:
212 way
0-10bar
Flow channel 65-150mm
Detachable repair
Sealing material: NBR rubber - EPDM rubber - fluoro rubber
Suitable for water
Provide lP65 three-pole connector in accordance with UNl lSO 4400 (DIN 43650A)(Normally open type )
Product features
| General characteristics | |||
| Body material | Cast iron | ||
| Sealing material | NBR | EPDM | VITON |
| Temperature | 80℃ | 140℃ | 150℃ |
| Insulation grade | H | ||
| Voltage | 220-230VAC 50-60Hz | 100-120VAC 60Hz | 12-24DC |
| Power | 22VA | 22VA | 18W |
| Ambient temperature | -10℃-80℃ | ||
| Installation | Installed according to the flow direction of the valve body.to improve the life and reliability, install it horizontal upward is best | ||
| Connection | The standard is G, and the thread requirements such as NPT can be selected. | ||
| Voltage fluctuation | ±10% | ||
| Can be equipped with coil | A21 | ||
| Specification sheet (Flange interface) | ||||||||
| Connection way | Flow aperturemm mm | Pressure difference(BAR) | Model(voltage is 220v)X=N or E or V | |||||
| MiniMum pressure | Maximum working pressure | |||||||
| Air，gas | Water, liquid | |||||||
| AC | DC | AC | DC | |||||
| 65F | 65 | 0 | 10 | 8 | 10 | 8 | DF-65F-A4X | |
| 85F | 85 | 0 | 10 | 8 | 10 | 8 | DF-80F-B4X | |
| 100F | 100 | 0 | 10 | 8 | 10 | 8 | DF-100F-C4X | |
| 125F | 125 | 0 | 10 | 8 | 10 | 8 | DF-125F-D4X | |
| 150F | 150 | 0 | 10 | 8 | 10 | 8 | DF-150F-E4X | |
